- Aluminum PCB (Matel Core LED light Circuit Board)
- 【Brief】：
Model Number:customized
Type:consumer electronics pcba
Place of Origin:Guangdong, China
Brand Name:LDES
Supplier Type:OEM
Copper Thickness:1 oz
Product name:Audio equipment Aluminum PCB
Way of shipping:EMS/UPS/DHL/Fedex
Solder mask color:green/blue/black
Package:vacuum package/ESD package
Samples order:welcome
Application:led light
Service:EMS.ODM.OEM
Certificate:ISO/RoHS/TS16949
PCB Item:Circuit Board Service
Lead Time:Quick Turn 24 hours
Delivery Time:3-5days
- 【Series】：Aluminum PCB
Matel Core LED light PCB Circuit Board Fabrication
1.Introduction of Matel Core LED light PCB Circuit Board Fabrication
Landes is capable of providing full turnkey and partial turnkey printed circuit board assembly services. For full turnkey, we take care of the entire process,
including preparation of Printed Circuit Boards, procurement of components, online order tracking, continuous monitoring of quality and final assembly.
Whereas for partial turnkey, the customer can provide the PCBs and certain components, and the remaining parts will be handled by us.
Features-Our Products Advantage
1. Over 10 years experience manufacturer in PCB Assemble and PCB field.
2. Big scale of producing makes sure that your purchase cost is lower.
3. Advanced production line guarantees stable quality and long life span.
4. Produce almost any PCB as your requirement.
5. 100% test for all customized PCB products.
6. One-stop Service ,we can help to purchase the components.
Metal Core PCB Capability
| Our Capability | |
| Materials | Aluminum ,copper |
| Maximum Lager Count | 4 Layers |
| Maximum Panel Size | 17″ x 23″ (432 x 584 mm2) |
| Min. Board Thickness | 1.0mm Al, 4 mils (0.1 mm) FR4 |
| Copper Clad (inner) | 1/2 oz, 1 oz, 2 oz, 3 oz, 4oz |
| Copper Clad (outer) | 1/2 oz, 1 oz, 2 oz, 3 oz, 4 oz |
| Surface Finishes | ENTEK 106A, Immersion Gold, HAL, immersion silver |
| Solder Mask | LPI: Taiyo PSR 4000, Tamura DS2200, Probimer 77MA |
| Minimum Trace (width) | 12.0 mils (0.30 mm) |
| Minimum Trace (spacing) | 12.0 mils (0.30 mm) |
| Minimum PAD-TO-PAD TOL. | ± 3 mils (± 0.76 mm) |
| Hole Size Tolerance (NPTH) | ± 2 mils (± 0.05 mm) |
| Hole Size Tolerance (PTH) | ± 3 mils (± 0.076 mm) |
| Minimum Hole Size | 20 mils (0.50 mm) |
| Outline Dimensional Tol. | < ± 10 mils (0.25 mm) |
| Ionic Cleanliness | < 5 mg/in2 of NaCl (0.775 mg/cm2) |
| Impedance Control | ± 10% (Differential) |
| Warpage | < 1% |
